Seasonic Prime Fanless PX-500 500W Platinum PSU (SSR-500PL)
FEATURE SUMMARY| Technical Specifications | ||
| 80PLUS | Platinum | |
| Cybenetics Efficiency Level | TBA | |
| Cybenetics Noise Level | TBA | |
| Form Factor | Intel ATX 12V | |
| Dimensions | 140 mm (L) x 150 mm (W) x 86 mm (H) | |
| Fan Information | Fan Size | N/A |
| Fan Control | N/A | |
| Fan Bearing | N/A | |
| Life Expectancy | N/A | |
| Cable Information | Modularity | Fully Modular |
| Cable type | Webbed cables (MB, CPU, PCIe) Flat black cables |
|
| Electrical Features | Operating Temperature | 0 - 50C (derating from 100% to 80% from 40C to 50C) |
| MTBF @ 25 C, excl. fan | 150,000 hours | |
| AC Input | Full Range | |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
| Warranty | 12 Years |
Power Output | ||||||
|---|---|---|---|---|---|---|
| AC Input | Voltage: 100 V - 240 V |
|||||
Current: 7 - 4 A | ||||||
Frequency: 50 Hz - 60 Hz | ||||||
| DC Output | Rail |
+3.3 V |
+5 V |
+12 V |
-12 V |
+5 VSB |
Maximum Power | 20 A | 20 A | 41 A | 0.3 A | 3 A |
|
100 W | 492 W | 3.6 W | 15 W |
|||
Total Continuous Power | 500 W |
NOTE FROM SELLER:
Direct from Manufacturers & Suppliers: We source our products directly from approved manufacturers and suppliers, ensuring top-notch quality and competitive prices.
Nationwide Shipping: Although our business is based in Wellard, we ship from various locations across Australia for efficient delivery to your doorstep. Please note that stock availability on the website is for reference and may change between adding an item to your cart and order processing.
Handling Time: Our dedicated team requires 1-2 business days to carefully pick, pack, and arrange pickup by the courier service once your order is placed.
Delivery Times: Shipping times generally range from 1-7 business days for metropolitan areas and 3-14 business days for regional areas. Shipping times may vary due to external factors beyond our control, such as weather or courier delays.
Cancellation and Return Policy:
We aim to dispatch all products within 1-2 working days after full payment is received. Once we confirm that your order is being processed, cancellation is not possible. The postage fee is non-refundable. Extra postage fees may apply for re-delivery or re-direction requests.
Ensure your shipping address is correct when placing your order, as address changes cannot be made after payment.
Returns are accepted within 30 days of purchase. Items must be unused, in their original packaging, and in resellable condition. For defective products, a free return label will be provided. If you return an item due to a change of mind, a 15% re-stocking fee and any postage costs will be deducted from your refund.
Please note that some products may become undeliverable once processing starts. In such cases, we may cancel your order and issue a full refund.
Delivery typically takes 2-14 business days. We recommend providing a valid contact number for delivery follow-up. Items will be sent via Australia Post or a courier, depending on size and weight.
Important Notice: Delivery Restrictions for Some Products
Please be aware that delivery restrictions apply to certain products. We are unable to process orders for delivery to the following postcodes: 885, 2222, 2449, 2818, 2827, 2829, 2836, 2839, 2874, 2898, 3724, 4477, 4490, 4626, 4822, 4871, 4875, 6044, 6209, 6224, 6290, 6442, 6536, 6562, 6707, 6713, 6725, 6728, 6743, 6751, 6753, 6754, 7255, 7256, 7258, 7260. Orders for these postcodes will be cancelled and refunded.
By completing your purchase, you agree to the postage and handling terms outlined above.
Seasonic Prime Fanless PX-500 500W Platinum PSU (SSR-500PL)
- Description
-
Seasonic Prime Fanless PX-500 500W Platinum PSU (SSR-500PL)
FEATURE SUMMARY- 80 PLUS Platinum certified
- Micro Tolerance Load Regulation (0.5%)
- True Fanless Design
- Multi-GPU setup
- Gold plated connectors
- 12 years warranty
Technical Specifications 80PLUS Platinum Cybenetics Efficiency Level TBA Cybenetics Noise Level TBA Form Factor Intel ATX 12V Dimensions 140 mm (L) x 150 mm (W) x 86 mm (H) Fan Information Fan Size N/A Fan Control N/A Fan Bearing N/A Life Expectancy N/A Cable Information Modularity Fully Modular Cable type Webbed cables (MB, CPU, PCIe)
Flat black cablesElectrical Features Operating Temperature 0 - 50C (derating from 100% to 80% from 40C to 50C) MTBF @ 25 C, excl. fan 150,000 hours AC Input Full Range Protection OPP, OVP, UVP, OCP, OTP, SCP Safety and Environmental Safety and EMC cTUVus, TUV, CB, CCC, BSMI, EAC, CE Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH Warranty 12 Years Power OutputAC Input Voltage: 100 V - 240 VCurrent: 7 - 4 AFrequency: 50 Hz - 60 HzDC Output Rail+3.3 V+5 V+12 V-12 V+5 VSBMaximum Power20 A20 A41 A0.3 A3 A100 W492 W3.6 W15 WTotal Continuous Power500 WNOTE FROM SELLER:
